As modern branch footprints continue to shrink, recycling technology must be designed to fit into more space-constrained areas. By providing high processing efficiency, big capacity and bulk cash recycling capability, P5800 is the ideal solution for financial institutions to meet requirements of branch automation and create a perfect environment to focus more on customer service and sales.


Optimized Configuration

Flexibly configurable to cash deposit only, dispensing only, cash deposit and dispensing or cash recycling, easily meeting requirements of different transaction regulations and networks.

Unrivalled Innovation

The intelligent cassette can be exchanged among P5800, GRG P2800 Series deposit machines and Cash recyclers to reduce cash handling cost. Comprehensive software solution offers a multi-parties’ remote monitoring and management.

Premier Security

UL291 Level 1 safe, built-in fraud resistant card-reader, optional vibration alarm and remote monitoring software solution ensure a secure transaction environment. PCI EPP is available on P5800, which enables P5800 to be suitable for self-service application.

Serial Number Tracking (opt.)

Featured with the OCR technology, P5800 can capture serial number of notes, Serial number can be used for fraud and deposit shrinkage management as it makes the cash management transparent and traceable.


    Controlling Unit

  • Intel® Atom™ D2550 1.86G CPU, 4G RAM 500G HHD
  • Windows® 7
  • Banknote Processing Unit

  • Deposit/Dispensing speed: 8 notes per second Escrow capacity: 200 notes
  • Up to 4 recycling cassettes and 1 acceptance cassette Cassette capacity: max. 3,000 notes *
  • Acceptance cassette capacity: max. 2,000 notes

Customer Interfaces

  • Display
  • 7" LCD touch screen Keypad:
  • Tactile 4*4 alphanumeric keypad
  • PCI compliant EPP Card reader:
  • Motorized card reader, Hi-Co & Lo-Co track read
  • Anti-skimming design
  • Card return on power failure (opt.)
  • DIP card reader (opt.) Receipt printer:
  • 48mm 203DPI graphical thermal printer Contactless card reader/ Fingerprint scanner (opt.) Barcode reader (opt.)

Security Physical

  • Mechanical combination lock
  • Electronic lock (opt.)
  • Standard UL291 Level 1 safe PIN Pad shield
  • EMV compliant
  • Contactless IC card reader compliant with QPBOC

Working Environment

  • Temperature:
  • Indoor: 32°F(0 °C) to 104°F(40°C) Outdoor: -31°F(-35 °C) to 122°F(50°C) (Optional heating unit is required )
  • Relative humidity: 20% to 95% non-condensing
  • Dimensions & Weight
  • Height: 37.8 in. (960.3mm) Width: 21.2 in. (538mm) Depth: 45.7 in. (1161.8mm) Weight: 1013bs (460kg)
